Toyota Push Switch with Green LED – 12V 3A ON/OFF + Momentary

Upgrade your Toyota’s interior controls with this 12V 3A OEM-Style Green LED Push Switch. Built tough with IP68 waterproofing, laser-etched symbols, and a clean OEM look, this switch is compatible with multiple Toyota models and installs in minutes. Includes both ON/OFF and momentary (GARAGE or HORN) functionality.

Key Features

• OEM-style black hard surface rocker switch
• Single pole single throw (SPST) ON/OFF and momentary (ON) OFF functions
• Laser-etched icons for GARAGE and HORN – long-lasting markings
• Green LED illumination – upper light ON when switch is pressed
• Lower light can be wired into dash illumination circuit
• IP68 waterproof rating – rugged and off-road ready
• Wiring harness included for quick install
• Installs in under 10 minutes using factory mounting hole

Specifications

• Voltage: 12V
• Current: 3A
• LED Colour: Green
• Function: ON/OFF (SPST) & Momentary (ON) OFF
• Face Size: 32.5mm × 22mm (1.28" × 0.87")
• Material: ABS
• Waterproof Rating: IP68
• Certifications: CE
• Includes Wiring: Yes

What’s Included

• 1 × Push Switch with Green LED (GARAGE or HORN function)
• 1 × Pre-wired Connector Harness

Vehicle Fitment

• Toyota Prado 150 Series (2010–Current)
• Toyota Prado 200 Series (2008–Current)
• Toyota LandCruiser 200 Series (2008–Current)
• Toyota RAV4 (2006–2011)
• Toyota Hilux GUN Series (09/2015–Current)
• Toyota HiAce (2014–Current)

Wiring Diagram

• ① Green Wire – Connect from your power source with an inline fuse
• ② Red Wire 1 – Connect to relay or accessory
• ③ Red Wire 2 – Connect to dash light circuit (optional)
• ④ Black Wire – Connect to ground

Notes

• Designed for existing Toyota OEM switch panels
• Switch locks into factory location with no cutting required
• ⚠️ Aftermarket product – not a genuine Toyota part
